Transforming Technologies Work Station Monitor Periodic Verification Unit User's Manual

Ohm Metrics
Work Station Monitor Periodic Verification Unit

Model CM420PV

TEST PROCEDURE:

1. Unplug the power supply to the CM420
2. Plug the Periodic Verification Unit (PVU) GROUND lead (Male Banana Plug) to the common ground at the
3. Connect the PVU BENCH lead (Male Phono Plug) to the CM420 BENCH plug-in.
4. Connect the power supply to the CM420 power plug-in.
5. The CM420 bench led should be
6. Plug the PVU OPERATOR LEFT lead (Banana Male Plug) to the CM420 LEFT OPERATOR remote jack.
7. Plug the PVU OPERATOR RIGHT lead (Banana Male Plug) to the CM420 RIGHT OPERATOR remote
8. Press the OPERATOR LEFT push button on the PVU and the LEFT OPERATOR led on the CM420 should change from a blinking red to green.
9. Release the PVU’s OPERATOR LEFT push button and the LEFT OPERATOR led on the CM420 should change to a blinking red, with momentary beeps up to a maximum of 7 to 12 beeps.
10. Press the BENCH push button on the PVU and the BENCH led on the CM420 should change to red, with constant
11. Release the PVU’s BENCH push button and the BENCH led on the CM420 should change to green, with no beeps.
12. Press the OPERATOR RIGHT push button on the PVU and the RIGHT OPERA- TOR led on the CM420 should change from a blinking red to
13. Release the PVU’s OPERATOR RIGHT push button and the RIGHT OPERATOR led on the CM420 should change to a blinking red, with momentary beeps up to a maximum of 7 to 12 beeps.
